The Dodge MagnaGear XTR combines planetary and helical gearing for high-torque, harsh-duty applications such as mining, aggregate and grain handling, with industry-leading bearing ratings, a standard dual purgeable HNBR seal system and EP lubricant-compatible backstops. Each size comes in right-angle and parallel-shaft versions; on the product page you choose the ratio, solid or hollow output shaft, hand and backstop direction.
Jump to: Sizes | Catalogs & manuals
MagnaGear XTR sizes
Sizes: G100 | G150 | G210 | G285 | G390 | G525 | G600 | G700 | G920 | G1400 | G2100 | G3500
| Size | Right angle | Parallel shaft |
|---|---|---|
| G100 | G100HR Right angle, 180 part numbers | G100HP Parallel shaft, 228 part numbers |
| G150 | G150HR Right angle, 180 part numbers | G150HP Parallel shaft, 228 part numbers |
| G210 | G210HR Right angle, 180 part numbers | G210HP Parallel shaft, 228 part numbers |
| G285 | G285HR Right angle, 180 part numbers | G285HP Parallel shaft, 228 part numbers |
| G390 | G390HR Right angle, 180 part numbers | G390HP Parallel shaft, 228 part numbers |
| G525 | G525HRS Right angle, 90 part numbers | G525HPS Parallel shaft, 72 part numbers |
| G600 | G600HR Right angle, 180 part numbers | G600HP Parallel shaft, 228 part numbers |
| G700 | G700HRS Right angle, 90 part numbers | G700HPS Parallel shaft, 72 part numbers |
| G920 | G920HRS Right angle, 90 part numbers | G920HPS Parallel shaft, 72 part numbers |
| G1400 | G1400HRS Right angle, 90 part numbers | G1400HPH Parallel shaft, 60 part numbers |
| G2100 | G2100HRS Right angle, 90 part numbers | G2100HPH Parallel shaft, 66 part numbers |
| G3500 | G3500HRS Right angle, 90 part numbers | G3500HPH Parallel shaft, 66 part numbers |
Fans, bushing kits and covers are in MagnaGear XTR accessories.
Not sure which one you need? Send your motor hp, output speed and shaft size through our quote form or call 800-985-6929 and we'll size it for you.
